Case Showcase

This page collects FastBee-Arduino cases deployed on real hardware. For more examples, see the Examples Index.

ESP32-S3 4-inch Touchscreen Device ControlTime, temperature & humidity, weather, history curves, and device control integrated on a 480 × 480 touchscreen, with Web drag-and-drop page editing and extensible components such as relays and stepper motors.ESP32-C3 Smart Switch PanelThe live+neutral wire panel links its three buttons one-to-one with relays, supports manual Web control and state sync, and enables single- or dual-gang channels based on the channels actually present.ESP32-C6 Full-Color LED Getting StartedUsing an ESP32-C6 DevKit, complete firmware flashing and an LED blink test within 5 minutes — experience the zero-code quick start flow.ESP32-C3 Temperature & Humidity Monitoring and DisplayCollect ambient temperature and humidity via a DHT11 sensor, show live readings on the OLED screen, and automatically trigger alarm rules when limits are exceeded.ESP32 Modbus Monitoring and ControlAn ESP32 IoT terminal collects Modbus RTU slave data over RS485 for industrial sensor monitoring and remote control.ECM50-A Networking Monitoring via 4G / Ethernet / WiFiThe ESP32-S3 based ECM50-A industrial device switches automatically between 4G cellular, W5500 Ethernet, and WiFi.ESP32 Puzhong DevKit Feature TestingComprehensive testing of GPIO, ADC, PWM, I2C, SPI, UART, display, and other peripheral features on the Puzhong ESP32 DevKit.ESP32-S3 Waveshare Industrial RelayAdaptation and verification of the Waveshare ESP32-S3 DevKit, covering typical scenarios such as WiFi, sensor acquisition, display driving, and MQTT reporting.

For more examples, see the Examples Index: a collection of example tutorials covering common sensors and modules.
